Sinusoidal (Sine Wave) Output
400 VA Output Power Maximum
Automatic Code-Compliant Testing
Automatic Dimming (0 to 10V) of Connected Load
Reduced Enclosure Size
Sinusoidal (Sine Wave) Output
400 VA Output Power Maximum
Automatic Code-Compliant Testing
Automatic Dimming (0 to 10V) of Connected Load
Reduced Enclosure Size
|
Model #
|
12NC
|
|
ELIS400I2UO30ADI2
|
913702486201
|
|
UL Listed for the US and Canada
|
UL924 Emergency Lighting Compliant
For Field Installation (Indoor and Damp) |
|
Maximum Output Power
|
400VA
|
|
Total Connected Output Load
|
Dimmable light loads: 800 W Maximum Input Power Non-Dimmable lighting loads: 400 VA Maximum Input Power |
|
Illumination Time
|
90 Minutes
|
|
AC Input Voltage
|
120 VAC, 60 Hz or 277 VAC, 60 Hz
|
|
AC Input Current
|
1000 mA Max, 120Vac or
360 mA Max, 277Vac |
|
Battery
|
4 ea. required Maintenance-Free Lithium-Ion Battery |
|
Recharge Time
|
24 Hours
|
|
Charging Indicator Light / Test Switch
|
Metal, Vandal Resistant Integrated LED / Test Switch
|
|
Output Voltage, Automatically Selected
|
120 VAC +/- 10%, or 277 VAC +/- 10%
|
|
Output Frequency
|
60 Hz, ± 5%
|
|
Temperature Rating (Ambient)
|
68° F to 86° F (20° C to 30° C)
|
|
Dimensions
|
12.0” H x 12.5” W x 10.0” D
(317mm x 305mm x 254mm) |
|
Weight
|
Enclosure and Electronics only: 16 lbs. (7.26 kg) Batteries total: 24.4 lbs. (11.1 kg) |
|
Warranty
|
5 Years (not including the batteries) 3 year battery warranty, plus 4 additional years pro-rata |
