10 W Class 2 Output
FirstLink Compatible for Automated Testing and Reporting
FirstLink Compatible for Automated Testing and Reporting
ABConnect Equipped (No Enable Connector)
ABConnect Equipped (No Enable Connector)
|
Model #
|
12NC
|
|
BSL10T4UAK55PKFLI2
|
913702493001
|
|
UL LISTED FOR US & CANADA
|
Listed to UL924 and tested to CSA 22.2 No. 141 CEC Title 20 Compliant |
|
Illumination Time
|
90 Minutes
|
|
Initial Light Output
|
Approximately 1500 Lumens (assuming a LED load efficacy of 150 lumens/watt)
|
|
Full Warranty
|
5 Years (NOT pro-rata)
|
|
Universal Input Voltage
|
120-277 VAC, 50/60 Hz
|
|
Output Voltage
|
15 - 54 VDC
|
|
Output Power
|
10.0 W initial (regulated)
|
|
Test SwitchTest Switch/Charging Indicator
|
Metal IP65 Bi-Color Illuminated Test Switch (Charge Indicator LED / Test Switch) with plenum rated cable
|
|
Battery
|
High-Temperature, Maintenance-Free
Lithium-Ion Battery 7- to 10-Year Life Expectancy |
|
Recharge Time
|
24 Hours
|
|
Temperature Rating (Ambient)
|
0°C to +55°C (32°F to 131°F)
Case: Tc (max): 63°C |
|
Dimensions
|
16.6” x 1.18” x 1.0” (424 mm x 30 mm x 25.4 mm) Mounting Center: 16.3” (415 mm) |
|
Weight
|
1.2 lbs (0.54 kg)
|
