Linear non-isolated fixed output window & Industry

Philips Xitanium 100W 0.15-0.5A 300V iXt 230V

Xitanium-100W-150mA-500mA-300V-iXt-230V-BS-angle

การดาวน์โหลดยอดนิยม

ดูการดาวน์โหลดทั้งหมด

คำบรรยายผลิตภัณฑ์

Philips Xitanium 100W 0.15-0.5A 300V iXt 230V

รหัสการสั่งซื้อ: 929001506606

รหัสการสั่งซื้อแบบเต็ม: 871869655591000

Nominal lifetime
100,000 hour(s)
Lighting Technology
LED
Isolation Class
Non-isolated

Line Frequency
50 to 60 Hz
Input Frequency
50 to 60 Hz
Mains voltage operation (DC)
168-275 V
Total Harmonic Distortion IEC (Max)
20 %
Power Consumption
106 W
Output Current Ripple (Max)
4 %
Maximum Efficiency at Full Load
94.1 %
Output Current (Max)
500 mA
Output Current (Nom)
325 mA
Output Current Tolerance (Max)
5 %
Mains voltage performance (DC)
186-250 V
Earth Leakage Current (Max)
0.5 mA
Power Factor (Fraction)
0.9
Open Circuit Voltage (DC) (Max)
330 V
Protection Level Up (L-N) at 5 kA (Max)
2 kV
Protection Level Up (LN-Earth) at 5 kA (Max)
4 kV
Input Current (Nom)
460 mA
Input current (AC)
460 mA
Input current (DC)
460 mA
Inrush Current Peak (Max)
9 A
Inrush Current Peak (Nom)
9 A
Output Power (Max)
100 W
Output Power (Nom)
100 W
Default output current
150 mA
Inrush Current Width to 50% of Peak
65 µs
Power Factor 100% Load (Max)
0.9
Energy Metering
No
Constant Current (CC)
True
Constant Voltage (CV)
False
Diagnostics
False
Output Power (Min)
28 W
Output Current (Min)
150 mA
Output Voltage (Max)
300 V
Output Voltage (Min)
100 V
Number of Products on MCB (16A Type B) (Max)
26
Number of Products on MCB (16A Type-C) (Max)
26 piece/unit
Protection class IEC
Safety class I
Surge Protection (Common/Differential)
EN61547 (L-L 2kV, L-G 4kV) kV
Adjustable Output Current
LEDSet/Resistor SimpleSet/NFC
