Philips DRUM, Pendant-mounted, 3D printed, 16.5 W, D218 mm, 2181 lm, 4000 K, Hoogglanzende reflector, IP20, EL-DC

TC KT PS 20S/830 PSE WH401 T102

Productomschrijving

Pendant-mounted, D218 mm, Polycarbonaat, Wit, Hangend, Voedingsunit, DC-compatibel voor centrale noodverlichting, 2181 lm, 16.5 W, 132 lm/W, 4000 K, (0.43, 0.40) SDCM < 5, Bundelhoek 90°, Hoogglanzende reflector, IP 20 | Bescherming tegen vingers, IK02 | 0,2 J standaard, Veiligheidsklasse II, 2 insteekconnectors, 2-polig, Doorvoerbedrading, 1 fase, Centrale gelijkstroomwerking centrale noodverlichting

Bestelcode: 912500100337
Volledige bestelcode: 871869606843400

Specificaties

  • Aantal VSA's
    1 unit
  • Driver/VSA inbegrepen
    Ja
  • Servicetag
    Ja
  • Waardeschaal
    Best
  • Garantieperiode
    5 jaar

Downloads

Brochures

Productbrochure
Localized commercial leaflet 912500100337 nl_BE pdf 330.9 kB

Brochures

Installatie-instructies
Drum Track-mounted Downlight Installation Instructions pdf 1.4 MB

Beeldmateriaal

Product-Photographs-912500100337_EU
Meerdere materialen
Product-Diagrams-912500100337_EU
Meerdere materialen

Lichttechnische files

IES
IES File - TC KT PS 20S/830 PSE WH401 T102 ies 993 B
