Essential SmartBright Solar Flood G2
Philips BVC080 LED25/MCCT G2 Solar
Product Description
Philips BVC080 LED25/MCCT G2 Solar
Order code:
911401807303
Full order code:
872110332404799
Specifications
Expand all
General Information
Driver included
Yes
Warranty period
2 years
Light Technical
Luminous Flux
2,500 lm
Correlated Color Temperature (Nom)
Selectable
Luminous Efficacy (rated) (Nom)
160 lm/W
Color rendering index (CRI)
>70
Operating and Electrical
Battery type
LiFePO4
Battery ampere hour
5 Ah
Battery voltage
9.6 V
Battery charging & discharging cycles
1000
Panel type
Mono crystalline
Panel voltage
14 V
Charge controller type
PWM
Charge controller wattage
15.6 W
Cable connection kit
Included
Cable
5m cable for Solar panel connection included
Grid connection type
Off grid
Controls and Dimming
Dimmable
Preset Dimming
Configurability
Not configurable
Control interface
-
Solar dimming profile
different modes by remote control
Mechanical and Housing
Housing Color
Grey
Overall length
272 mm
Overall width
204 mm
Overall height
50 mm
Dimensions (Height x Width x Depth)
50 x 204 x 272 mm
Material
Polycarbonate
Battery location
inbuilt luminaire housing
Ingress protection code
IP65 [Dust penetration-protected, jet-proof]
Mech. impact protection code
IK06 [1 J]
Optical cover type
Polycarbonate bowl/cover
Net Weight (Piece)
2.650 kg
Approval and Application
CE mark
Yes
EU RoHS compliant
Yes
Ambient temperature range
0 °C to 50 °C
Over Time Performance (IEC Compliant)
Median useful life L70B50
35,000 hour(s)
Product Data
Order product name
BVC080 LED25/MCCT G2 Solar
Full product name
BVC080 LED25/MCCT G2 Solar
Full product code
872110332404799
Order code
911401807303
Material Nr. (12NC)
911401807303
Numerator - Quantity Per Pack
1
EAN/UPC - Product/Case
8721103324047
Numerator - Packs per outer box
4
EAN/UPC - Case
8721103324085
Installation diagrams
Dimension Drawing (without table) - BVC080 LED25/MCCT G2 Solar
download
Downloads
Leaflets
Product leaflet
Localized commercial leaflet 911401807303 en_EG
pdf 518.6 kB
Visuals
Product-Photographs-911401807303_EU
Multiple assets
Product-Diagrams-911401807303_EU
Multiple assets
Software plugins
IES
IES File - BVC080 LED25/MCCT G2 Solar
IES 12.6 kB
